Solar Panel Lipo Charger MPPT CN3791

Solar Panel Lipo Charger MPPT CN3791

Solar maximum power point tracking (MPPT) is to ensure that the light intensity change, photovoltaic cells output maximum power, to make full use of solar energy. In general, need to use a switch-mode DC-DC converter to realize the MPPT function, keep the output voltage, and charging current product maximize (output).

Adopts the model of switch step-down DC-DC conversion way to realize tracking function of maximum power point of PV cells, the input voltage 6V/9V/12V/18V, very suitable for the application of the input voltage and battery voltage difference is bigger.

Charging management board features:
1. The high-end technology MPPT solar maximum power tracking charging management chip, with a trickle, constant current, constant voltage charging management.
2. Imported high-frequency low conduction resistance doubles MOS tube, large current diode, efficient flat power inductor, alloy current sense resistor.
3. The bottom of the large aluminum heat sink guarantees the stability of the large current length of time and work.
4. High speed and efficient way of charging.
5. Double status indicator light, not the battery when the red light flashing green light normally on, red light when charging, auto stop when full of green light at the same time

Features:

  • Solar Panel Input voltage: 6V/9V/12V/18V
  • Output voltage: 3.7 V nominal full of termination voltage of 4.2 V lithium battery
  • Output current: Maximum constant current 3A
  • Size: 45mm*31mm
  • Package List:

  • 1 x Solar Panel Lipo Charger MPPT CN3791
